Model CSB - Differential Pressure Gauges :: Products

Range	-1 to 70 kg/cm² & 100 to 400 kg/cm²
Instrument Connection	1/2" BSP(F)
Process Connection Size	1/4” , 3/8”, 1/2", M20
Process Connection Type	NPT, BSP, G, R, Metric etc
Diaphragm	AISI 316L SS, Monel, Hastelloy C
Bottom Chamber	AISI 316 SS, Monel, Hastelloy C
Sealing Gasket	P.T.F.E
Filling Fluid	Silicon Oil
Compatible Models	PB, PS, PP, PJ, PBQ
Options	Flushing Ring (FR) for drainage With Capillary (Up to 20 Mtrs) PTFE Protection on Diaphragm

Diaphragm seals are provided in the instruments like pressure gauges, switches, transmitters in order to isolate the sensing element from the main service due to its corrosive, viscous and sedimented nature and to avoid clogging and solidification.
