| Standard Follows | EN 837-3 |
| Nominal Dial Size (mm) | 63, 80, 100 |
| Range | 0 to 2 kg/cm² |
| Accuracy | ± 5.0% of F.S (Ascending) |
| Mounting Type | In line |
| Migration | No Migration : Zero leakage from High to Low port |
| Connection Size | 1/4" NPT(F) with center distance of 54mm |
| Sensing Element | Diaphragm |
| Case & Bezel | AISI 304 SS |
| Pointer | Aluminium, Black |
| Window (Glass) | Acrylic |
| Body Material | Aluminum |
| Options | With Electric Contact, With Liquid Filled Red Follower Pointer |
