DIFFERENTIAL PRESSURE GAUGE DOUBLE DIAPHRAGM TYPE - MODEL PHP

PHP (Piston Operated)
Standard Follows EN 837-3
Nominal Dial Size (mm) 100, 15050, 63, 100, 150
Range 0 to 70 kg/cm²
Accuracy ±2.0% of F.S (Ascending)
Mounting Type In line / Bottom / Back
Migration Minor from High to Low port
Connection Size 1/4" NPT(F)
Sensing Element Piston
Case & Bezel AISI 304 SS
Pointer Aluminium, Black
Movement AISI 304 SS / AISI 316 SS
Window (Glass) Shatterproof
Body Material Aluminum, Brass, AISI 316 SS
Static Pressure Max up to 20 bar
Overload 4 times of range, Max up to 20 bar
Options With Electric Contact, With Liquid Filled
Red Follower Pointer
