STAINLESS STEEL LOW & HIGH PRESSURE GAUGE DIAPHRAGM TYPE - MODEL PD

PD (All Stainless Steel - Diaphragm Type)
Reference Standard EN 837-3 / IS 3624
Nominal Dial Size (mm) 100, 150
Range H.P. : -1 to 0, 0 to 10 kg/cm²
L.P. : -6000mmWC to 0, 0 to 6000mmWC
Accuracy ±1.6% of F.S
Mounting Type Click Here
Connection Size 1/4”, 3/8”, 1/2", M20, Flanged
Connection Type NPT, BSP, G, R, Metric etc
Case & Bezel Bayonet AISI 304 SS / AISI 316 SS
Top / Bottom Chamber AISI 304 SS / AISI 316 SS
Diaphragm (Sensing Element) AISI 316L SS / Monel / Hastelloy C
Pointer Aluminium, Zero Adjustable
Movement AISI 304 SS / AISI 316 SS
Window (Glass) Shatterproof / Plexy / Toughened
Enclosure Protection IP 65
Options PTFE Protection on Diaphragm
PTFE lining of Flanged Connection

Download Send Enquiry

Applications

  • Schaffer Gauge are suitable for Pharmaceutical, Chemical
  • Petrochemical, Oil & gas, Refinery, Paper & Pulp, Sugar, Breweries
  • Foods & Breweries, Cement Industries, etc.
