STAINLESS STEEL PRESSURE GAUGE SOLID FRONT TYPE - MODEL PS

PS (All Stainless Steel - High Safety Type)
Reference Standard EN 837-1 / IS 3624
Nominal Dial Size (mm) 100, 150
Range -1 to 0, 0 to 0.6, 0 to 600 kg/cm²
Accuracy ±1.0% of F.S / ±1.6% of F.S
Mounting Type Click Here
Connection Size 1/4” , 3/8”, 1/2", M20
Connection Type NPT, BSP, G, R, Metric etc
Socket AISI 316L SS / Monel
Sensing Element AISI 316L SS / Monel (Bourdon)
Case & Bezel Bayonet AISI 304 SS / AISI 316 SS
Pointer Aluminium, Zero Adjustable
Movement AISI 304 SS / AISI 316 SS
Window (Glass) Shatterproof / Plexy / Toughned
Enclosure Protection IP 65 / IP 66 / IP 67
Options Dampening Liquid Glycerine Filled
Conformity as per NACE Standard
Movement with Dampening Jelly

Download Send Enquiry

Applications

  • Food & Beverage
  • Pharmaceutical
  • Draft Measurement
  • Conventional & Nuclear Power Plants
