| Reference Standard | EN 837-1 / IS 3624 |
| Nominal Dial Size (mm) | 100 |
| Range | -30inHg to 0, 0 to 400 kg/cm² |
| Accuracy | ±1.6% of F.S |
| Mounting Type | Click Here |
| Connection Size | 1/4”, 3/8” |
| Connection Type | NPT, BSP, G, R, Metric etc |
| Socket | Copper Alloy |
| Sensing Element | Copper Alloy (Bourdon) |
| Case & Bezel | ABS (Screwed) |
| Pointer | Aluminium, Fixed |
| Movement | Copper Alloy |
| Window (Glass) | Plain |
| Enclosure Protection | IP 55 |
| Options | Oxygen Service (For Dry Version) Ammonia Range (Temperature scale) |
