STAINLESS STEEL CASE BRASS INTERNAL PRESSURE GAUGE BOURDON TUBE TYPE - MODEL PT

PT (Stainless Steel Case - Brass Internal)
Reference Standard EN 837-1 / IS 3624
Nominal Dial Size (mm) 50, 63, 100
Range -1 to 400 kg/cm²
Accuracy ±1.6% of F.S
Mounting Type Click Here
Connection Size 1/4” , 3/8”
Connection Type NPT, BSP, G, R, Metric etc
Socket / Bourdon AISI 316L SS / Monel
Case & Bezel AISI 304 SS / AISI 316 SS
Pointer Aluminium, Fixed
Movement Copper Alloy
Window (Glass) Plexy
Enclosure Protection IP 65
Options Dampening Liquid Glycerine Filled
Ammonia Range (Temperature scale)
Oxygen Service (For Dry Version)

Download Send Enquiry

Applications

  • Oil
  • Water Treatment Plant
  • Pneumatics
  • Hydraulic
  • Pumps & Compressors
  • Diesal Engines
