STAINLESS STEEL PRESSURE GAUGE BOURDON TUBE TYPE - MODEL PB

PB (All Stainless Steel - Bourdon Type)
Reference Standard EN 837-1 / IS 3624
Nominal Dial Size (mm) 100, 125, 150, 250
Range -1 to 1600 kg/cm²
Accuracy ±1.0% of F.S / ±1.6% of F.S
Mounting Type Click Here
Connection Size 1/4” , 3/8”, 1/2", M20
Connection Type NPT, BSP, G, R, Metric etc
Socket / Bourdon AISI 316L SS / Monel
Case & Bezel Bayonet AISI 304 SS / AISI 316 SS
Pointer Aluminium, Zero Adjustable
Movement AISI 304 SS / AISI 316 SS
Window (Glass) Shatterproof / Plexy / Toughened
Enclosure Protection IP 65 / IP 66 / IP 67
Options Dampening Liquid Glycerin Filled
Conformity as per NACE Standard
Ammonia Range (With Temperature scale)
Oxygen Service (For Dry Version)

Download Send Enquiry

Applications

  • Food & Beverage
  • Pharmaceutical
  • Chemical & Petrochemical Industries
  • Conventional & Nuclear Power Plants
  • Pumps
  • Hydro-cleaning Machines
  • Engine compressor, turbines and diesel engine
  • Refrigerating Plants
