DIFFERENTIAL PRESSURE GAUGE BELLOW TYPE - MODEL PBQ

PBQ (Bellow Operated)
Standard Follows EN 837-3
Nominal Dial Size (mm) 150
Range 0 to 6000 mmWC & 0 to 6 kg/cm²
Accuracy ±1.0% of F.S
Mounting Type Wall / Surface with Bottom
Connection Size 2 x 1/2" NPT(M) or BSP(M)
Sensing Element Bellow AISI 316L SS
Case & Bezel Bayonet AISI 304 SS
Pointer Aluminium, Black Zero Adjustable
Movement Bayonet AISI 304 SS
Window (Glass) Shatterproof Glass
Options Available with Filled version
Conformity as per NACE Standard
Red Follower Pointer

Download Send Enquiry

Applications

  • Chemical & Petrochemical Industries
  • Food & Beverage
  • Pharmaceutical industry
  • Refinery
  • Aerospace
  • Nuclear power Plant
  • Fertilizer
  • Sugar
  • Cement
  • Pulp, paper & allied Industries
