THERMOWELLS FABRICATED (SCREWED) - MODEL TW3

TW3
Construction Pipe Fabricated
Connection Type Threaded
Form of Shank Strialght
Material of Construction AISI 304 SS / AISI 304L SS / AISI 316 SS / AISI 316L SS
Process Connection 3/8" to 1" NPT, BSP, G, R
Instrument Connection 3/8" to 1" NPT, BSP, G, R
Bore Diameter/Pipe Size 7 x 10, 7 x 12, 9 x 14, 10 x 12, 12 x 14,16 x 12 OR Pipe 1/8" to 1/2" Sch 40 to 160
Type Of Head Hex, Round
Ext / Lagging Length 50mm
Insertion Length As per Customer
Options Plug & Chain in AISI 304 SS

Download Send Enquiry

Applications

  • HVAC
  • Utilities
  • Chemical & Petrochemical Plants
  • On Shore & Off Shore
  • Engineering
  • Other similar process Industries
