DIFFERENTIAL PRESSURE GAUGE DOUBLE DIAPHRAGM TYPE - MODEL POD

POD (2 x Diaphragm Operated)
Standard Follows EN 837-3
Nominal Dial Size (mm) 100, 150
Range 0 to 25 kg/cm²
Accuracy ±1.6% of F.S
Mounting Type horizontal or vertical pipe mounting
Connection Size 2 x 1/4" NPT(F)
Wetted Part Diaphragm (Duratherm)
Case & Bezel Bayonet AISI 304 SS
Pointer Aluminium, Black
Movement AISI 304 SS
Window (Glass) Shatterproof Glass
Static Pressure Max. 100 kg/cm²
Overload up to 200 kg/cm²
Options Chemical Seal, Manifolds

Download Send Enquiry

Applications

  • Flow measurement
  • Petro-chemical industry
  • Filter applications
  • General industry
  • Shipping industry
  • off shore
