DIFFERENTIAL PRESSURE GAUGE CAPSULE TYPE - MODEL PDD

PDD (1 x Diaphragm Operated)
Standard Follows EN 837-3
Nominal Dial Size (mm) 100, 150
Range 0 to 16 kg/cm²
Accuracy ±2.5% of F.S
Mounting Type Bottom / Back / with Bracket
Connection Size 2 x 1/2" NPT or 1/2" BSP
Wetted Part Diaphragm (Duratherm) - AISI 316L SS
Case & Bezel Bayonet AISI 304 SS
Pointer Aluminium, Black
Movement Brass Nickel Plated
Window (Glass) Shatterproof Glass
Static Pressure Max up to 20 kg/cm²
Overload Max up to 20 kg/cm²
Options With Chemical Seal Other connection available
With Swivel Adaptors

Download Send Enquiry

Applications

  • Flow measurement
  • Petro-chemical industry
  • Filter applications
  • General industry
  • Oil and gas industry
  • Shipping industry
  • off shore
