STAINLESS STEEL PRESSURE GAUGE ELECTRIC CONTACT - MODEL PJ

PJ (All Stainless Steel - Electric Contact Type)
Reference Standard EN 837-1 / IS 3624
Nominal Dial Size (mm) 100, 150
Range -1 to 1600 kg/cm²
Accuracy ±1.0% of F.S
Mounting Type Click Here
Connection Size 1/4” , 3/8”, 1/2", M20
Connection Type NPT, BSP, G, R, Metric etc
Socket / Bourdon AISI 316L SS / Monel
Case & Bezel Bayonet AISI 304 SS / AISI 316 SS
Pointer Aluminium, Zero Adjustable
Movement AISI 304 SS / AISI 316 SS
Window (Glass) Polycarbonate Dome
Enclosure Protection IP 65
Electric Wiring DIN connector
Options Conformity as per NACE Standard
Die Electric oil Filled Movement with
Dampening Jelly

Download Send Enquiry

Applications

  • Pumps, Motors & Presses
  • Hydraulic & Pneumatic Equipments
  • Chemical & Petrochemical Industries
