THERMOWELLS FABRICATED (VANSTONE) - MODEL TW5

TW5
Construction Van Stone - Drilled Type
Flange Facing Type Flange RF
Form of Shank Partial Taper / Full Taper
Material of Construction AISI 304 SS / AISI 304L SS / AISI 316 SS / AISI 316L SS
Process Connection 1", 1½", 2" RF
Instrument Connection 1/2" NPT, 1/2" BSP
Bore Diameter 6.5, 6.6, 7.0, 8.0, 8.5, 9.0, 10.0, 10.5, 11.0, 13.0, 13.50
Type Of Head Round
Ext / Lagging Length 50mm
Insertion Length 1000 mm (Max)
Options Wake Frequency Calculation
Conformity as per NACE Standard

Download Send Enquiry

Applications

  • Chemical & Petrochemical Plants
  • On Shore & Off Shore
  • Engineering
  • Other similar process Industries
