DIAPHRAGM SEAL SLIP RING COUPLED TYPE - MODEL CSO

CSO (Slip Ring Coupled Type)
Range -1 to 70 kg/cm²
Instrument Connection 1/2" BSP(F)
Process Connection Size 1/2" BSP(M)
Diaphragm AISI 316L SS
Body AISI 304 SS / AISI 316 SS
Filling Fluid Silicon Oil
Mounting With Capillary
Compatible Models PP, PS, PB, PJ, PBQ
Options Capillary Up to 3 Meter
Conformity as per NACE Standard

Download Send Enquiry

Applications

  • Diaphragm seals are provided in the instruments like pressure gauges, switches, transmitters in order to isolate the sensing element from the main service due to its corrosive, viscous and sedimented nature and to avoid clogging and solidification.
  • These kind of seals are widely used in the viscous & corrosive services where flushing is required periodically & frequently.
