THERMOWELLS BAR STOCK (WELD IN/ SOCKET WELD) - MODEL TW6

TW6
Construction Socket Weld - Drilled Type
Connection Type Weld - in, Socket Weld
Form of Shank Straight / Straight Reduce Tip / Partial Taper / Full Taper
Material of Construction AISI 304 SS / AISI 304L SS / AISI 316 SS / AISI 316L SS
Process Connection Customised Requirement
Instrument Connection 1/2" to 1" NPT, BSP, G, R
Bore Diameter/Pipe Size 6.5, 6.6, 7.0, 8.0, 8.5, 9.0, 10.0, 10.5, 11.0, 13.0, 13.50
Type Of Head Round
Ext / Lagging Length 50mm
Insertion Length 1000 mm (Max)
Options Wake Frequency Calculation
Plug & Chain in AISI 304 SS
Conformity as per NACE Standard

Download Send Enquiry

Applications

  • Chemical & Petrochemical Plants
  • On Shore & Off Shore
  • Engineering
  • Other similar process Industries
