Model CSI - Differential Pressure Gauges :: Products

Range	-1 to 70 kg/cm² & 100 to 400 kg/cm²
Instrument Connection	1/2" BSP(F)
Process Connection Size	Flange as per ANSI,JIS,DIN,BS
Diaphragm	AISI 316L SS, Monel, Hastelloy C
Top Chamber	AISI 304 SS
Bottom Chamber ("I" Section)	AISI 316 SS, Monel, Hastelloy C
Filling Fluid	Silicon Oil
Flange Size	1" and below only
Compatible Models	PP, PS, PB, PJ, PBQ
Options	Capillary Up to 20 Meter Conformity as per NACE Standard

Diaphragm seals are provided in the instruments like pressure gauges, switches, transmitters in order to isolate the sensing element from the main service due to its corrosive, viscous and sedimented nature and to avoid clogging and solidification. This can be widely used with anti corriosive treatment/protection & various flanged sizes.
